STAY CONNECTED WITH PORTAL EV

Technical Specifications

Wireless Connectivity

• Quad-stream AC2200 Wave-2 WiFi
• Simultaneous dual-band WiFi (2.4GHz and 5GHz)
• Band steering automatically selects 2.4GHz or 5GHz for best performance
• Continuous 2.4GHz and 5GHz scanners allow operation in restricted 5GHz ranges (UNII-2A, UNII-2C, U-NII-2e) for consistently fast and reliable performance
• Bluetooth® 4.1 Low-Energy: Supporting smartphones, tablets and IoT devices

Advanced Radios

• 5GHz 4×4 high-powered agile wide-band 802.11a/n/ac Wave-2
• 2.4GHz 3×3 high-powered 802.11b/g/n
• Nine (9) large internal antenna with discrete high-power amplifiers to provide coverage to large homes up to 3,000 ft² / 280 m²

MU-MIMO

• Multi-User MIMO for simultaneous streaming and gaming on multiple devices

Beamforming

• Explicit transmit beamforming for improved range and coverage

Ports

• Five (5) Gigabit Ethernet Ports – 4 LAN, 1 WAN
• Two USB 2.0 Ports

Mesh 2.0

• For larger multi-story homes greater than 3,000 ft² / 280 m²
• Enterprise-grade Mesh with dynamic layer-2 routing
• Near Zero-Interference, Auto-Detect, Easy one-touch setup
• Wireless and wired backhaul available

Security

• Continuous Intrusion Monitoring and remote alerts to smartphone
• Ultra-secure Web GUI interface with proprietary 2-factor authentication
• VPN for secure remote access
• WiFi Protected Access® (WPA/WPA2—PSK)
• Parental Controls to manage web filtering and accessibility
• Geo-fenced Guest access with rolling code passwords and easy smartphone setup and authentication
• Double firewall protection (SPI and NAT)

Additional

• QoS prioritizes network traffic by application and device
• DLNA® server to find and play your media on TVs and game consoles

Support for 3 years. Covers installation assistance, set up, optimization, Web Gui access, basic support 8am-5pm EST with 4 hour response time.
